You Are Here : Home > Products > Push-Pull Cable > GJ1106A Down the hole drill throttle cable control lever
Description

Fixed type

panel

Thickness of shell

28mm

Distance of holes

100mm

Inner diameter of fixed orifice

Φ6.5

Material of gear, rack

Powder metallurgy or 45 steel

Material of shell

Aluminum alloy

Material of spline

45 steelafter processing, quality firmer

Application

Be fit for down the hole drill, truck with crane, firefighting truck

Principle

Locking at any position, trimming by rotating handle,control a piece of push-pull cable or pull cable.

Press the button and control a piece of push pull cable or pull cable , reduce or increase throttle

Release the button and lock automatically throttle

Micro adjustment by rotating handle

Function

manual control accelerator

Characteristic

Install dust cover, good seal

Material of tube is stainless steel or general steel

Customs length and thick of push pull cables

Customs the shape of ball knob can install button and electric wire



Specification
